| Swing | 11" | 279.4 mm |
| Centers | 18" | 457.2 mm |
| Threading | Inch/Metric | Inch/Metric |
| Power | 3 hp | 2.2 kW |
| RPM | 4,000 RPM | 4,000 RPM |
| Dimensions | 74"x30"x66" | 74"x30"x66" |
| Weight | 2420 lb | 2420 lb |
Cross Slide Travel..........................................................6″
Compound Slide Travel..................................................3″
Quick Action Compound Slide Motion.......................0.1″
Tailstock Quill Travel.............................................3 – 3/4″
Inch Threads (36)..........................................11 – 108 TPI
Metric Threads (36)...................................0.275 – 2.7mm
Carriage Slide Powerfeed Range....3/16″ – 4″ per minute
Cross Slide Powerfeed Range.........5⁄16” – 7″ per minute
5C Collet Quick Action Production Style Collet Closer
Coolant and Chip Shield
Tool Box, Tool Kit, and one Adjustable Height Tool Holder
Test Bar and 64 Collet Storage Wheel
Manuals
Halogen Work Light
