SMART MACHINE TOOL NL 2000BSY Reduced from $179,900.00 to $139,900.00

NL 2000BSY
CAPACITY
Swing over the bed 31.89”
Maximum turning diameter 16.18”
Maximum turning length 28.94”

MAIN SPINDLE
Chuck Size 8”
Spindle nose A2-6
Main spindle motor 20 / 25 hp
Spindle speed 4,500 rpm
Draw Tube ID 2.64”
C axis minimum 0.001 deg

SUB SPINDLE
Chuck Size 8”
Spindle nose A2-6

Main spindle motor 15 / 20 hp
Spindle speed 5,000 rpm
Draw Tube ID 2.0”
C axis minimum 0.001 deg

BED SLIDE & CARRIAGE
Rapid traverse (X / Y / Z / ZB) 1,181 ipm / 394 ipm / 1,181 ipm / 1,181 ipm
Guide ways Box Way
Bed structure 30° Slant bed

TURRET
Number of tool stations 12 (24) tools (BMT55)
Turret indexing speed (1 station) 0.15 seconds
Rotating Tool Spindle Motor 5 / 7.4 hp
Rotating Tool RPM 5,000 RPM
MACHINE SIZE

Floor space requirements
including
conveyor (L x W x H)
184.7” x 71.6” 188.6” x 71.6”

CNC Model Fanuc 0i-TF Plus (15” touch screen)
