| Live Tooling | No | No |
| Y-Axis | No | No |
| Sub Spindle | No | No |
| Swing | 30" | 762 mm |
| Machining Length | 80" | 2,032 mm |
| X Travel | 1,958" | 49,733 mm |
| Z Travel | 80" | 2,032 mm |
| Chuck Size | 25" | 635 mm |
| Bar Capacity | 10" | 254 mm |
| Power | 30 hp | 22.4 kW |
| Max RPM | 1,000 RPM | 1,000 RPM |
| Turning Dia | 22" | 558.8 mm |
| Tailstock | Yes | Yes |
| Barfeed | No | No |
| Control | CNC (FANUC) | CNC (FANUC) |
| Dimensions | 222x85x80 | 222x85x80 |
| Weight | 13230 | 13230 |
Power at 220v 3 phase
30 HP standard
10” Spindle Bore, A2-15 spindle, 18-600 RPM (Low Range: 18-186, High Range: 60-600)
Rear Chuck Adaptor
Chip Conveyor
Serial Number: S/N 30TR10110-008
25” chuck installed and included
*Factory on-site 2-day machine operation and program training – includes expenses $4,995.
