| Live Tooling | No | No |
| Y-Axis | No | No |
| Sub Spindle | No | No |
| Swing | 18.5" | 469.9 mm |
| Machining Length | 11.8" | 299.72 mm |
| # Axis | 2 | 2 |
| X Travel | 6.9" | 175.26 mm |
| Z Travel | 14.7" | 373.38 mm |
| Chuck Size | 8" | 203.2 mm |
| Bar Capacity | 2" | 50.8 mm |
| Power | 15 hp | 11.2 kW |
| Max RPM | 3,200 RPM | 3,200 RPM |
| Turning Dia | 12.6" | 320.04 mm |
| Tailstock | Yes | Yes |
| Barfeed | No | No |
| Control | CNC (Fanuc Oi-T) | CNC (Fanuc Oi-T) |
| Dimensions | 71"L x 54"W x 65"H | 71"L x 54"W x 65"H |
| Weight | 7,100 Lbs | 7,100 Lbs |
Gantry Loader Interface
Parts Catcher (Prepped for)
Auto Door
Chuck Air Blow
Programmable Tailstock Quill
Bar Feed Interface
Tool Setter
Rear Discharge Chip Conveyor
Misc. Tool Holders
8" 3-Jaw Chuck
