| Live Tooling | No | No |
| Y-Axis | No | No |
| Sub Spindle | No | No |
| Swing | 24.4" | 619.76 mm |
| Machining Length | 26.4" | 670.56 mm |
| # Axis | 2 | 2 |
| X Travel | 9.1" | 231.14 mm |
| Z Travel | 24.4" | 619.76 mm |
| Chuck Size | 10" | 254 mm |
| Bar Capacity | 3.2" | 81.28 mm |
| Power | 20 hp | 14.9 kW |
| Max RPM | 3,500 RPM | 3,500 RPM |
| Turning Dia | 14.17" | 359.92 mm |
| Tailstock | Yes | Yes |
| Barfeed | No | No |
| Control | CNC (OSP5020L) | CNC (OSP5020L) |
Tailstock
10" Chuck
Chip Conveyor
Mist Collector
