| X | 30" | 762 mm |
| Y | 16" | 406.4 mm |
| Z | 19" | 482.6 mm |
| Power | 15 hp | 11.2 kW |
| RPM | 6,000 RPM | 6,000 RPM |
| # ATC | 30 | 30 |
| Taper | 40 | 40 |
| Table-W | 410 mm | 16.142" |
| Table-L | 1,150 mm | 45.276" |
| Control | CNC (Yasnac) | CNC (Yasnac) |
| Dimensions | 116"x112"x109" | 116"x112"x109" |
| Weight | 12,000lbs | 12,000lbs |
TABLE SIZE: 45.28" X 16.14"
MACHINE TRAVELS (X/Y/Z): 29.92' X 17.32" X 19.09"
TABLE CAPACITY: 1,102 LBS.
SPINDLE TAPER: BT 40
SPINDLE SPEEDS: 6,000 MAX RPM
RAPID TRAVERSE RATE (X/Y/Z): 590 / 590 / 472 IPM
MAXIMUM CUTTING FEED RATE: 197 IPM
TOOL CHANGER STYLE: TWIN-ARM
TOOL CHANGER CAPACITY: 30 STATIONS
TOOL CHANGE TIME: 1.9 SECONDS TOOL TO TOOL
MAX TOOL LENGTH: 13.7"
MAX TOOL WEIGHT: 22 LBS.
SPINDLE DRIVE: 10 HP
SPINDLE TO TABLE DISTANCE: 5.91" - 27.17"
SPINDLE CENTER TO COLUMN DISTANCE: 18.5
