| Live Tooling | No | No |
| Y-Axis | No | No |
| Sub Spindle | No | No |
| Swing | 24.8" | 629.92 mm |
| Machining Length | 78" | 1,981.2 mm |
| # Axis | 2 | 2 |
| X Travel | 15.3" | 388.62 mm |
| Z Travel | 78" | 1,981.2 mm |
| Chuck Size | 16" | 406.4 mm |
| Bar Capacity | 4" | 101.6 mm |
| Power | 25 hp | 18.6 kW |
| Max RPM | 2,500 RPM | 2,500 RPM |
| Tailstock | Yes | Yes |
| Barfeed | No | No |
| Control | CNC (Siemens) | CNC (Siemens) |
| Dimensions | bc + 82"L x 90"W x 82"H | bc + 82"L x 90"W x 82"H |
| Weight | 11,000 Lbs | 11,000 Lbs |
16" 4-Jaw Chuck
Tool Post
Tailstock
Coolant Tank
Oiler
Manual Pulse Generator
