CSA certified meeting CSA C22.2 #71.2-10 and UL 987-7th standards!
SPECIFICATIONS:
Motor: 3 HP, 220V, single-phase, 12A, TEFC capacitor start induction, 60 Hz
RPM: 1725
Precision-ground cast-iron table
Table size: 26-3/4" x 19" x 1-1/2" thick
Floor to table height: 37-1/2"
Cutting capacity/throat: 18-1/4"
Maximum cutting height: 12"
Blade size: 143" long
Blade width range: 1/8" - 1-1/4"
2 Blade speeds: 1700, 3500 FPM
Wheels: fully balanced cast-iron with polyurethane tires
Wheel covers: pre-formed, hinged steel
Blade guides: dual ball-bearing with full enclosure protection
Bearings: sealed and permanently lubricated
Footprint: 29-1/2" x 17-3/4"
Overall size: 76" H x 36" W x 32" D
Approximate shipping weight: 480 lbs.
FEATURES:
Blade tension indicator
Micro-adjusting geared table tilting mechanism
Height scale measurement
Fence with scale and magnifying window
Deluxe cast-iron fence with extruded-aluminum re-saw fence
Miter gauge
4" dust port x 2
Table tilt 5° left, 45° right
Quick-change blade release/tensioning
Rack and Pinion upper guide adjustment
Foot brake
Cast-iron trunnion
Includes 3/4" 6-TPI blade
