| Chuck Size | 15" | 381 mm |
| Swing | 30" | 762 mm |
| Live Tooling | No | No |
| Sub Spindle | No | No |
| Turning Dia | 26" | 660.4 mm |
| Power | 5 hp | 3.7 kW |
| Max RPM | 1,750 RPM | 1,750 RPM |
| Tailstock | '' | '' |
| Dimensions | 6ft x 4ft x 7 ft high | 6ft x 4ft x 7 ft high |
| Weight | 5000 LBS | 5000 LBS |
Lenco T-400-2000mhz control with 17″ LCD
5 HP Spindle energy efficient Motor
Max 1750 rpm spindle speed with electrical speed control
Hardened & Ground precision guide ways
Zero backlash precision ball screws hardened & ground for high accuracy and long lasting efficiency
Wheel specific main frame built with small footprint for large wheels and long term reliability
Precisely measured for positioning accuracy & repeatability Upgrades can be done via our staff in the USA anywhere in the world via internet as well as trouble shooting
14” Wide bed ways design to provide maximum rigidity & stability
Tool box and Tools
Coolant System
Largest wheel in jaws 26″ standard
This equipment has been sold. Similar equipment available now is shown below.
