| Chuck Size | 10" | 254 mm |
| Swing | 24" | 609.6 mm |
| Machining Length | 18.7" | 474.98 mm |
| Bar Capacity | 3" | 76.2 mm |
| Live Tooling | No | No |
| Y-Axis Milling | No | No |
| Sub Spindle | No | No |
| # of Turrets | 1 | 1 |
| Turning Dia | 13.78" | 350.01 mm |
| Power | 35 hp | 26.1 kW |
| Max RPM | 4,000 RPM | 4,000 RPM |
| Tailstock | Yes | Yes |
| Control | CNC (Mazatrol 640) | CNC (Mazatrol 640) |
Max Swing: 24.02"
Turn Diameter: 13.78"
Machining Length: 99.61"
Spindle Bore: 3.46"
Bar capacity: 3.03"
Chuck Size: 10"
Spindle Speed: 4,000 RPM
Main Motor: 35 HP
Tailstock: Yes
Turret Position: 12
Equipped With:
Mazatrol 640T Nexus CNC Control Tailstock
Chip Conveyor
10" Chuck
Mazatrol 640T CNC Control
Tailstock
