| Power | 5.4 hp | 4 kW |
| Saw Blade Dia. | 19.685" | 500 mm |
| Dimensions | 910mm Length X 1335mm Depth X 1840mm Height | 910mm Length X 1335mm Depth X 1840mm Height |
| Weight | 580 KG | 580 KG |
Tilting range pneumatically from 90° to 45° (optional intermediate angle)
For cutting range, see cutting diagram
Saw blade diameter 500 mm
Saw blade speed 2,800 rpm
Power supply 230/400 V, 3~, 50 Hz
Power output 4 kW
Compressed air supply 7 bar
Air consumption per working cycle 20 l without spraying, 32 l with spraying
Length 910 mm, depth 1,335 mm, height 1,840 mm, weight 580 kg
This equipment is currently unavailable. Similar equipment available now is shown below.
