| Table Dia | 63" | 1,600.2 mm |
| Swing | 78.7" | 1,999 mm |
| Work Ht-U/R | 63" | 1,600.2 mm |
| Power | 50 hp | 37.3 kW |
| RPM | 250 RPM | 250 RPM |
| Control | CNC (Fanuc 31iT) | CNC (Fanuc 31iT) |
Table Diameter: 63” 4-jaw independent Table
60/50 HP Motor
Maximum Swing/Cutting Dia.: 78.7”
Table Enclosed Splash Guard
Maximum Turning Height: 65”
Chip Conveyor
Ram Stroke: 35.4”
External Coolant System
Ram Size: 9.4”
Square External Coolant System
Table Load: 17,600 lbs.
2 Turning Holders
ATC: 24 pots (7 Turning + 16 Milling)
Live Spindle Taper CAT50: Live Spindle 20/25 HP Motor
Table Speed: 1-250 rpm
Live Spindle Speed: 15-2,000 rpm
Fanuc 31iT CNC,
Fanuc Servo Motors,
Air Blow Device,
Hydraulically Balanced Forged Steel Square Ram,
Foundation Bolts,
Plates,
Telescopic Cover for Cross Rail,
Spot Light,
Warning Light,
English Manuals.
Fanuc 31iT CNC
Coolant Thru the Spindle 230PSI
Four (4) Model 240 TC-01 Tool Holders ($ 12k value)
Splash Guard Enclosure
24 Station ATC
Hinge Type Chip Conveyor
2 std Turning Type Tool Holders
Air Blow Device
Spot Light
Warning Light
English Manuals
