SMART MACHINE TOOL NL 2000BSY CNC Turning Center W/ "Y" Axis Live Tooling and Sub-Spindle
ConditionNew
1 available
New
8" Chuck
5-Axis
Turning Dia of 16.18"
25hp,
max RPM of 6,000
Live Tooling
Sub Spindle
Y-Axis
***See attached brochure
NL 2000BSY
CAPACITY
Swing over the bed 31.89”
Maximum turning diameter 16.18”
Maximum turning length 28.94”
MAIN SPINDLE
Chuck Size 8”
Spindle nose A2-6
Main spindle motor 20 / 25 hp
Spindle speed 4,500 rpm
Draw Tube ID 2.64”
C axis minimum 0.001 deg
SUB SPINDLE
Chuck Size 8”
Spindle nose A2-6
Main spindle motor 15 / 20 hp
Spindle speed 5,000 rpm
Draw Tube ID 2.0”
C axis minimum 0.001 deg
BED SLIDE & CARRIAGE
Rapid traverse (X / Y / Z / ZB) 1,181 ipm / 394 ipm / 1,181 ipm / 1,181 ipm
Guide ways Box Way
Bed structure 30° Slant bed
TURRET
Number of tool stations 12 (24) tools (BMT55)
Turret indexing speed (1 station) 0.15 seconds
Rotating Tool Spindle Motor 5 / 7.4 hp
Rotating Tool RPM 5,000 RPM
MACHINE SIZE
Floor space requirements including
conveyor (L x W x H) 184.7” x 71.6” 188.6” x 71.6”
CNC
CNC Model Fanuc 0i-TF Plus (15” touch screen)
Tool Presetter
Oil Skimmer
Barfeeder Interface
Air Blow for Main/Sub Spindle
Manual Guide i
Pneumatic Parts Ejector
Sub Spindle Coolant Flush
(1) X-Axis Live Tool Holder
(1) Z-Axis Live Tool Holder
Add $8,000 for the Smart Value Package as follows:
Chip Conveyor - Side Discharge
290 PSI Coolant Pump
Internal Parts Catcher/Parts Conveyor (Max Diameter: 2.6”, Max Length: 4.5”, Max Weight: 6.6 lbs)
1 Set of Hard Jaws
3 Sets of Soft Jaws
3 Color Tower Light
8" Chuck
5-Axis
Turning Dia of 16.18"
25hp,
max RPM of 6,000
Live Tooling
Sub Spindle
Y-Axis
***See attached brochure
Imperial
| # Axis | 5 |
| Swing | 31.89" |
| Machining Length | 28.94" |
| Chuck Size | 8" |
| Bar Capacity | 2.5" |
| Power | 25 hp |
| Max RPM | 4,500 RPM |
| Turning Dia | 16.18" |
| Tailstock | No |
| Live Tooling | Yes |
| Sub Spindle | Yes |
| Y-Axis | Yes |
| Control | CNC (Fanuc OiTF) |
| Dimensions | 189" x 72" |
| Weight | 12,566 |
NL 2000BSY
CAPACITY
Swing over the bed 31.89”
Maximum turning diameter 16.18”
Maximum turning length 28.94”
MAIN SPINDLE
Chuck Size 8”
Spindle nose A2-6
Main spindle motor 20 / 25 hp
Spindle speed 4,500 rpm
Draw Tube ID 2.64”
C axis minimum 0.001 deg
SUB SPINDLE
Chuck Size 8”
Spindle nose A2-6
Main spindle motor 15 / 20 hp
Spindle speed 5,000 rpm
Draw Tube ID 2.0”
C axis minimum 0.001 deg
BED SLIDE & CARRIAGE
Rapid traverse (X / Y / Z / ZB) 1,181 ipm / 394 ipm / 1,181 ipm / 1,181 ipm
Guide ways Box Way
Bed structure 30° Slant bed
TURRET
Number of tool stations 12 (24) tools (BMT55)
Turret indexing speed (1 station) 0.15 seconds
Rotating Tool Spindle Motor 5 / 7.4 hp
Rotating Tool RPM 5,000 RPM
MACHINE SIZE
Floor space requirements including
conveyor (L x W x H) 184.7” x 71.6” 188.6” x 71.6”
CNC
CNC Model Fanuc 0i-TF Plus (15” touch screen)
Tool Presetter
Oil Skimmer
Barfeeder Interface
Air Blow for Main/Sub Spindle
Manual Guide i
Pneumatic Parts Ejector
Sub Spindle Coolant Flush
(1) X-Axis Live Tool Holder
(1) Z-Axis Live Tool Holder
Add $8,000 for the Smart Value Package as follows:
Chip Conveyor - Side Discharge
290 PSI Coolant Pump
Internal Parts Catcher/Parts Conveyor (Max Diameter: 2.6”, Max Length: 4.5”, Max Weight: 6.6 lbs)
1 Set of Hard Jaws
3 Sets of Soft Jaws
3 Color Tower Light
