SMART MACHINE TOOL NL 3500BY CNC Turning Center With "Y" Axis Live Tooling and Tailstock
ConditionUsed
1 available
$269,900.00 USD
Used SMART MACHINE TOOL NL 3500BY CNC lathe. A professional-grade machine for precision turning applications. Contact us for details.
NL 3500BY
CAPACITY
Swing over the bed 38.8”
Maximum turning diameter 16.9”
Maximum turning length 57.9”
MAIN SPINDLE
Chuck Size 15”
Spindle nose A2-11
Main spindle motor 40 hp
Spindle speed 2,000 rpm
Draw Tube ID 4.6”
BED SLIDE & CARRIAGE
Travels (X / Y / Z) 11.6” / 5.12” / 61.6” (±2.56)
Guide ways Box Way
Bed structure 30o Slant bed
TURRET
Number of tool stations 12 tools (24) (BMT65)
Turret indexing speed (1 station) 0.25 seconds
Rotating Tool Spindle Motor 14.7/10 hp
Rotating Tool RPM 5,000 rpm
TAILSTOCK
Tailstock travel 59.06"
Quill diameter 5.51"
Quill travel 4.72"
Tailstock center (Taper) MT #5
MACHINE SIZE
Floor space requirements including
conveyor (L x W) 250" x 89"
CNC
CNC Model Fanuc 0i-TF Plus (15” touch screen)
Tool Presetter
Oil Skimmer
Manual Guide i
(1) X-Axis Live Tool Holder
(1) Z-Axis Live Tool Holder
Add $6,000 for the Smart Value Package as Follows:
Chip Conveyor - Side Discharge
140 PSI Coolant Pump
1 Set of Hard Jaws
3 Sets of Soft Jaws
3 Color Tower Light
Used SMART MACHINE TOOL NL 3500BY CNC lathe. A professional-grade machine for precision turning applications. Contact us for details.
Imperial
| Chuck Size | 15" |
| Swing | 38.8" |
| Machining Length | 57.9" |
| Live Tooling | Yes |
| Y-Axis Milling | Yes |
| Sub Spindle | No |
| # of Turrets | 1 |
| Turning Dia | 16.9" |
| Power | 40 hp |
| Max RPM | 2,000 RPM |
| Tailstock | Yes |
| Control | CNC (Fanuc Oi-TF Plus) |
NL 3500BY
CAPACITY
Swing over the bed 38.8”
Maximum turning diameter 16.9”
Maximum turning length 57.9”
MAIN SPINDLE
Chuck Size 15”
Spindle nose A2-11
Main spindle motor 40 hp
Spindle speed 2,000 rpm
Draw Tube ID 4.6”
BED SLIDE & CARRIAGE
Travels (X / Y / Z) 11.6” / 5.12” / 61.6” (±2.56)
Guide ways Box Way
Bed structure 30o Slant bed
TURRET
Number of tool stations 12 tools (24) (BMT65)
Turret indexing speed (1 station) 0.25 seconds
Rotating Tool Spindle Motor 14.7/10 hp
Rotating Tool RPM 5,000 rpm
TAILSTOCK
Tailstock travel 59.06"
Quill diameter 5.51"
Quill travel 4.72"
Tailstock center (Taper) MT #5
MACHINE SIZE
Floor space requirements including
conveyor (L x W) 250" x 89"
CNC
CNC Model Fanuc 0i-TF Plus (15” touch screen)
Tool Presetter
Oil Skimmer
Manual Guide i
(1) X-Axis Live Tool Holder
(1) Z-Axis Live Tool Holder
Add $6,000 for the Smart Value Package as Follows:
Chip Conveyor - Side Discharge
140 PSI Coolant Pump
1 Set of Hard Jaws
3 Sets of Soft Jaws
3 Color Tower Light
